Sword of Orion and South

Emission/Reflection Complex in Orion

Uploaded 2/18/07

Select an image size for a larger view: 1024 x 768 1600 x 1200

 The composition of this image was VERY carefully chosen as to include a host of interesting objects near the Orion Nebula complex. The dim nebulosity covers an area in circular patch centered on M42/43 in the center. (This image was carefully flat fielded)

We start our journey into this exciting region with the central object M42. A bright core is surrounded by first blue, then pink wreaths of nebulosity, then again surrounded by an immense ring of blue reflection. Dark brown dust lanes cut into the nebula, blocking the light from our view. Just underneath the dark bay in M42 you will find M43 a bright but small coma shaped nebula consisting of both blue dust and pink gas.

Just below (north) M43 is a huge blue nebula Sharpless 2-279, with a purple heart - the Running Man Nebula. The purple coloration is from a small amount of emission nebulosity inside the core of the nebula shining through. It surrounds the collection of hot blue supergiant stars of the cluster NGC1977.

Below this object is a sparse but splashy open cluster with some reflection nebulosity, NGC1981. This 4th magnitude object has about 20 stars as part of the cluster.

Take a turn to the left now, and in the lower left corner is a very isolated streak of reflection nebulosity, IC420. It shines from the light of 8.2 magnitude SAO 132229, a type B7 star.

Now pan your attention to just above M42 (The Orion Nebula) and you will see two or three very bright stars forming a star cluster enveloped in some blue reflection nebulosity. This is NGC1980, a super bright combined magnitude of 2.5, spread over a quarter degree of sky. This is primary from its brightest component iota Orionis, a 6th magnitude O9 star.

Now we turn our gaze once again to the upper right part of the field. This is perhaps one of the most spectacular groupings in the entire sky of Herbig-Haro objects, or proto star cocoons. Look closely at the larger image, and you will see a small blue reflection nebula - NGC1999 with a dark spot on one side in the core of the complex, and just above, HH1 and HH2 seen here as a spectacular pair of blood red nebula. The elusive Waterfall nebula and Chevron Nebulas are to be found here as well.

Next, take a look in the upper right corner of the frame. The bright star 49 Orionis which is 4.8th magnitude illuminates IC430, a very dim streak shaped reflection nebula.

Finally, notice the huge circular brownish/red dust and gas cloud that surrounds the M42 complex over most of this image. While deep hydrogen images will reveal a fine textured detail in this envelope, It also is very dusty, and the overall tint is close to a yellowish red color.

Instrument: Stellarvue SV80s @ f/4.8 Platform: Astrophysics 1200 QMD Camera: Hutech Modified Canon XTi @ ISO800 Exposure: 6 x 10m, core 5s - 60s Filters: None Location: Payson, Arizona Elevation: 5150 ft. Sky: Seeing 3/10, Transparency 7/10 Outside Temperature: 35F Processing Tools: Photoshop CS2, Iris, Canon RAW HOME GALAXIES EMISSION NEBS REFLECTION NEBS COMETS GLOBULARS OPEN CLUST PLANETARIES LINKS FastCounter by bCentral
