This is my deepest
            image yet of this celestial splendor, a dying star in the winter
            Milkyway. Extreme care was taken to ensure correct coloration
            on both the stars and nebula when the luminance was incorporated.



Description:
            Composed of two parts, NGC650 & NGC651 this 12.2 magnitude
            planetary nebula displays very clearly the twin hoops or ears
            that are known to follow the magnetic field lines of the central
            star. With a size of 170 arcseconds, it rates as one of the larger
            of such objects with a 16th magnitude central star.


Processing notes:
            The LRGB color correction technique was used to its fullest capacity
            here, to enable the enhanced LRGB to match the G2V calibrated
            RGB image as closely as possible. A screened duplicate layer
            was combined with the luminance data using a mask made from the
            image itself, converted to a negative. This enabled rich detail
            in both the brightest and dimmest areas of nebulosity.

Instrument:  12.5" f/5 Home made Newtonian
Platform:  Astrophysics 1200 QMD
CCD Camera:  SBIG 10XME NABG with Enhanced Water Cooling
Guider: SBIG ST4
Exposure:  HaRGB = 80:20:20:20 (RGB NOT Binned)
RGB Combine Ratio:  1: 1.05: 1.11
Filters:  AstroDon RGB Tricolor
Location:  Payson, Arizona
Elevation:  5150 ft.
Sky:  Seeing FWHM = 5 arcsec (Maxim DL - 10min subframe), Transparency 8/10
Outside Temperature:  35 F
CCD Temperature:  -30 C
Processing Tools:  Maxim DL, Gralaks Sigma, Photoshop, PixInsight, Starizona Debloomer.
